Wireless Access Point
User Guide
Parameter Description
2.4 GHz SSID It specifies the currently enabled SSID(s) over the 2.4 GHz band of the AP.
5 GHz SSID It specifies the currently enabled SSID(s) over the 5 GHz band of the AP.
VLAN ID
It specifies the VLAN IDs corresponding to SSIDs. By default, this value is
1000.
After the QVLAN function is enabled, the wireless ports corresponding to
SSIDs functions as access ports. The PVID of an access port is the same as
its VLAN ID.
If the QVLAN function is enabled, tagged data received by a port of the AP is forwarded to
the other ports of the VLAN corresponding to the VID in the data, whereas untagged data
received by a port of the AP is forwarded to the other ports of the VLAN corresponding to
the PVID of the port that receives the data.
The following table describes how ports of different link types process transmitted and
received data.
Port
Method to process received data
Method to process transmitted
data
Tagged
data
Untagged data
Access
Forward the data
to other ports of
the VLAN
corresponding to
the VID in the
data.
Forward the data to
the other ports of the
VLAN corresponding
to the PVID of the
port that receives the
data.
Transmit data after removing
tags from the data.
Trunk
If the VID and PVID of a port are
the same, transmit data after
removing tags from the data.
If the VID and PVID of a port are
different, transmit data without
removing tags from the data.
7.8.3 Example
Networking requirement
A hotel has the following WiFi network coverage requirements:
− Guests are allowed to connect to VLAN 2 and only able to access the internet.
− Hotel staffs are allowed to connect to VLAN 3 and only able to access the intranet.
− Hotel administrators are allowed to connect to VLAN 4, able to access both the
intranet and the internet.
Assume that the SSID for guests is internet, the SSID for staffs is oa and the SSID for
82
