Wireless Access Point
User Guide
Parameter Default Value
5 GHz
The AP allows 4 SSIDs over the 5 GHz
band. SSID is IP-COM_XXXXXX, and
“XXXXXX” ranges from the sum of last 6
digits of the AP’s LAN MAC address and 8
to the sum of the 6 digits and 11.
As the primary SSID, the first SSID in the
drop-down-list box is enabled by default,
and the other SSIDs are disabled.
Broadcast SSID Enable
Isolate Client Disable
WMF Enable
Suppress Broadcast Probe
Response
Disable
Max. Number of Clients 48
Chinese SSID Encoding UTF-8
Security Mode None
Radio Settings
Enable Wireless Enable
Network
Mode
2.4 GHz 11b/g/n
5 GHz 11ac
Channel Auto
Channel
Bandwidth
2.4 GHz 20/40 MHz
5 GHz 80 MHz
Lock Channel Enable
Transmit
Power
2.4 GHz 11 dBm
5 GHz 14 dBm
Lock Power Enable
Preamble Long Preamble
Short GI Enable
Isolate SSID Disable
Radio
Optimization
Beacon Interval 100 ms
Fragment Threshold 2346
RTS Threshold 2347
121
