Wireless Access Point
User Guide
System LED indicator
System LED
indicator
Solid on
- The system is starting.
- If the indicator keeps solid on after the AP finishes
startup, it indicates that the system is faulty.
Blinking The AP is working properly.
Off
- The AP is not powered on.
- The LED indicator has been turned off.
- The AP is faulty.
RESET button
When the system LED indicator blinks, hold down the RESET button for about 8 seconds. The
AP is reset successfully when the system LED indicator gets solid on.
LAN port
It is a 10/100 Mbps auto-negotiation port used to exchange data with other devices or
connect to IEEE 802.3af/at PoE power supply using an Ethernet cable to power on the AP.
PWR port
It is a power port used to connect to a DC power resource using the power adapter included
in the package.
