TEDS
Adjusts the channel scaling settings with sensor settings from the TEDS chip of the connected sensor.
Offset
Executes an offset adjust for selected channels, resp. for all channels defined within a group. The reference
value or target value can be defined by the user. As soon as the adjustment has finished, offset values,
available measurement ranges and results of the adjustment command are displayed.
All active channels which support the offset adjust are displayed.
Select those channels who need to be adjusted:
all channels, the highlighted channels, all channels of a group.
Press Start to execute adjustment.
Offset values, available measurement ranges and results of the adjustment command are displayed.
Press Export to save adjustment values to CSV or HTML file. These values will not saved in the module.
