IPEmotion
IPETRONIK PlugIn X V02.14.00
IPETRONIK GmbH & Co. KG
64/ 87
Filter (Hardware, Software)
Deactivating the hardware filter causes the risk of incorrect acquisition through aliasing effects!
The hardware filter blocks interfering frequency spectra (harmonics) in periodic signals.
Go to PlugIn Options and activate Aliasing-free filter settings (Options tab)
in order to automatically adapt software filter settings for aliasing free measurement.
Depending on the device
- Off
- 1.2 kHz Mx-SENS
Mx-SENS2
- 4.8 kHz Sx-STG
- 12 kHz Mx-SENS2 4
