IRMA MATRIX R2 CAN Installation manual
released
Rev. 1.6
2018-09
Document information
Title of document: IRMA MATRIX R2 CAN Installation manual
File name: KDIA_IRMA-MATRIX_R2_Installation-manual-CAN_1.6_en.pdf
Revision: 1.6
Edition (YYYY-MM): 2018-09
Type of document: Customer documentation (KD)
Status: released
Validity
Sensors and connectors covered by this document:
Product
Item type
Item Description
IRMA MATRIX
DIST500
-A DIST500.7-A07.OC
Sensor, surface mount
version
IRMA MATRIX
DIST500
-F DIST500.7-F07.OC
Sensor, flush mount version
IRMA MATRIX
sCON
-S sCON-S-CAN-20-Kn-x
Connector (standard) with a
CAN interface for MATRIX
sensors
IRMA MATRIX
sCON
-S sCON-S-CAN-ETH-23-Kn-x-y
Connector (standard) with
CAN and Ethernet interfaces
for MATRIX sensors
IRMA MATRIX
sCON
-F-12 sCON-F-12-CC-E
Connector with one
Ethernet and two CAN
interfaces for MATRIX
sensor DIST500-F (flush-
mount version)
