IRIS IRMA MATRIX 2

00
BB_DIST500-E
DIN ISO 2768 mK
DIN ISO 13715
1:1
iris-GmbH
infrared & intelligent sensors
www.irisgmbh.de
1 / 3
05.12.14JP
Index
Drawing-No.
free size tolerances
edge of workspace
Scale A4-Format
Discription
Drilling template IRMA MATRIX, Flush mount with threade bolt
mm (inch)
Surface
Material
Production status
iris-
Part-No.
Page
Creator
NameDate
ApprovedEditorDateDescription of changeIndex
Unit
We reserve all rights in this document and in the information contained therein. Reproduction, use or disclosure to third parties without express authority is strictly prohibited.
172±0.8
163±1
28±0.5
53
+1
5
0.3
R4
0.5
