4210 Flow Meter
Section 2 Programming
2-4
From time to time you will notice an arrow pointing to the edge
of the display. This indicates that additional choices are available
beyond what you can see on the display. By continuing to press
the right arrow key you can view these unseen menu options.
After reaching the furthest option, the arrow will move to the left
side of the display, indicating that there are options unseen to
the left. These will be the options you started with. If you want to
go back to one of them, use the left arrow key until the option
you need reappears. When the desired selection is flashing, just
press Enter. The display will then automatically advance to the
next step of the program.
All of the program steps contain several “substeps” that must all
be completed before you advance to the next program step. Other
steps, like Reset Totalizer, contain only a few substeps. Some
steps will require the entry of a numeric value. Program these
steps by using the number and decimal keys to enter the appro-
priate value.
Note that it is possible to program the flow meter in the shop,
rather than at the job site, with the exception of step 3, Adjust
Level/Parameters. To set level you must make an accurate mea-
surement of the level in the flow stream and then enter that
value. This can only be done at the job site.
If you are programming the flow meter for the first time, press
Enter, start with step 1, and go on from there. If the flow meter
has been in use and you need to change only part of the program,
you would more likely use the Go To Program Step key. With
this key you can go directly to the program step you need to
change, which saves time.
If you change an entry and do not like it you can make the
display revert to the original entry by pressing Clear Entry. If
you have already pressed Enter, however, the new value will be
in memory. To change it, press Exit Program. If you are in the
middle of a program step with multiple substeps, the flow meter
will display, “Changes have been made in step; press 0 to con-
tinue or 1 to discard.” If you press 1, the display will return to
normal and the last step you were working on will revert to its
previous selection. (Any program step you completely change
before exiting will remain changed.)
You can re-enter the program with either Enter or the Go To
Program Step keys. If you become confused while pro-
gramming, the best suggestion is to press Exit Program and
start over. Also remember that you can have the flow meter print
a complete list of your program choices by exiting the program
and by pressing the Print Program key as soon as the display
returns to the normal operating condition, displaying level and
total flow, etc.
Programming Steps:
1. Operating Mode
2. Flow Conversion
3. Adjust Level/Parameters
