B-1
4210 Flow Meter
Appendix B Programming Worksheet
• Use a photocopy of the worksheet on the following pages
to create a hard copy of the program you use in your
4210. Most program steps can be completed in the shop
without the flow meter being installed or at the job site.
However, please note the following:
• Do not attempt to fill out this form without first
studying the manual, especially Section 2. This section
describes the program in detail and offers reasons why
you might choose one option over another. This is partic-
ularly true for those using the flow meter for the first
time. Keep this worksheet as a record.
• Some of the menus shown on this sheet may not appear
on your flow meter. The reason is that you must make
choices from the first step forward that will prevent you
from choosing certain other options later on. Options
can appear at several points of the program. However,
menus pertaining to the options not chosen early on will
not appear later. Another example is the alarm dial-out
feature. This step requires your flow meter to have the
optional modem. If you do not have the modem, no
menus concerning dialout will appear.
• If, after filling out this chart, you cannot make some
menus appear that you need, recheck your Setup on the
flow meter to see that you have not accidentally locked
yourself out of a path by an incorrect early selection.
• If you only need to program the flow meter once, you can
write on this sheet. If you are doing temporary surveys,
or expect the program to change, make copies of these
sheets and write on the copies.
