4210 Flow Meter
Section 2 Programming
2-49
2.13 Step 8 - Printer Setup This step sets up the operation of the flow meter's internal
printer. This printer also functions as a plotter. Note that the
printer/plotter is capable of printing alphanumeric information
(words and numbers), and at the same time, plotting linear data
like flow, level, pH, etc.
The unit can print as many as three different data lines (named
A, B, and C) at the same time it regularly records other printed
information supplied from the flow meter. Program selections
made in this step will determine the appearance of the
printer/printer's chart.
The first menu will request the speed of the chart.
If you select OFF, the printer will be disabled. No data will be
printed on the chart. The flow meter will, however, still print
reports if you activate that function in step 9. The choice made
from the other speeds depends on the amount of data you need to
record on the chart.
If you are recording from a stable situation and are using only
one data line, and you want to achieve maximum life for the roll
of chart paper, you would select a lower speed for chart advance.
On the other hand, if there is a great deal of activity in your flow
stream, and you need to use all three data lines, selection of a
faster chart speed will probably produce a chart that is more
easily read and interpreted.
After you select the printer speed, the flow meter will ask you to
define what parameter input you want represented by Printer
Line A. The following display will appear:
(TEMPERATURE), (YSI pH), (YSI D.O.), (YSI CONDUC-
TIVITY), and (YSI TEMP) can also appear. Remember that
menus in parentheses may or may not appear due to previous
program selections. Either pH or D. O. may appear, but not both.
The various YSI options will only appear if you have enabled the
YSI 600 option in step 1. You must have the appropriate probes
to sense these conditions for the flow meter. Select OFF if you do
not wish to use this line.
If you select pH, D. O., TEMPERATURE, or any of the YSI
options, the flow meter will request that you set limits that will
serve as the bottom of the chart and the chart full-scale.
You would enter here the lowest pH value you expect to see in
your flow stream:
ENTER PRINTER SPEED
• OFF • • 1/2"/HR • • 1"/HR • • 2"/HR • • 4"/HR •
INPUT FOR PRINTER LINE A
• (LEVEL) • • (FLOW RATE) • • (pH) • • (D. O.) • • OFF •
PRINTER LINE A BOTTOM SCALE
X.XX pH (or other condition, as selected previously)
PRINTER LINE A FULL SCALE
X.XX pH (or other condition, as selected previously)
