4210 Flow Meter
Section 2 Programming
2-33
If you select RECTANGULAR for the Manning flow conversion,
the following displays will appear:
(Slope and roughness are entered the same as for ROUND
PIPE.) Then:
If you select TRAPEZOID for the Manning flow conversion, the
following displays will appear:
(Slope and roughness are entered as for ROUND PIPE.) Then:
Then:
2.7.4 Data Points Returning to step 2, FLOW CONVERSION TYPE, if you select
DATA POINTS, the following will appear:
Then:
This allows you to enter data points that are in different units
than you are using. Then:
If you press the right arrow key several times, the following
units will appear on the display:
GPM = gallons per minute; GPS = gallons per second, MGD =
million gallons per day, CFS = cubic feet per second; CFM = cubic
feet per minute, M3S = cubic meters per second; M3M = cubic
meters per minute; M3H = cubic meters per hour; M3D = cubic
meters per day; LPS = liters per second; CFD = cubic feet per
day; GPH = gallons per hour; AFD = acre-feet per day; CFH =
cubic feet per hour.
Data Point flow conversion allows you to enter measured level
and flow rate values for a number of different points. The 4210
Flow Meter can accept up to four sets of data points with each set
containing as many as fifty points.
MANNING RECTANGULAR
SLOPE = X.XXXXX ROUGH = X.XXX
MANNING RECTANGULAR
WIDTH = X.XXX FEET (or meters)
MANNING TRAPEZOID
SLOPE = X.XXXXX ROUGH = X.XXX
MANNING TRAPEZOID
TOP WIDTH = X.XXX FEET (or meters)
MANNING TRAPEZOID
BOTTOM WIDTH = X.XXX FEET (or meters)
SELECT DATA SET
• ONE • • TWO • • THREE • • FOUR • • (NONE) •
LEVEL UNITS FOR DATA POINT ENTRY
• FT • • IN • • M • • MM •
FLOW RATE UNITS
• GPM • • GPS • • MGD • • CFS • • CFM • • M3S • • M3H • • M3D •
FLOW RATE UNITS
• LPS • • CFD • • GPH • • AFD • • CFH • • CFM • • M3M •
