4210 Flow Meter
Appendix B Programming Worksheet
B-2
Step 1 - Setup
1. Select Option: Program, Setup. First, choose Setup and
work through the following menus.
2. Year:Month:Day:Hour:Min ____________________________
3. Site I.D. _______ (Any three-digit number)
4. Measurement Setup: Level Reading Interval, Minimum
Depth, Do/pH Reading Interval ________________________
5. Level Reading Interval: Continuous, 15 Sec, 30 Sec, 1 Min,
2 Min, 5 Min
6. Variable Blanking Distance = _________________________
7. (Job site only) Signal Strength ________________________ %
8. Do/pH Reading Interval: Continuous, 15 Sec, 30 Sec, 1Min,
2 Min, 5 Min _________________________________________
9. YSI 600 Reading Interval: Continuous, 15 Sec, 30 Sec,
1Min, 2 Min, 5 Min ___________________________________
10. Level Enable/Alarm: Hysteresis ________Feet (or Meters)
11. Flow Rate Enable/Alarm Hysteresis _______Units______
12. Temperature Enable/Alarm Hysteresis ______Deg. F (C)
13. pH Enable/Alarm Hysteresis ________pH units.
14. D.O. Enable/Alarm Hysteresis ________ppm.
15. YSI-pH Enable/Alarm Hysteresis ________pH units.
16. YSI-D.O. Enable/Alarm Hysteresis ________ppm/mg./L
17. YSI-Conductivity Enable /Alarm Hysteresis_______mS/cm
18. YSI-Temperature Enable/Alarm Hysteresis______Deg.
19. Optional Outputs: 4-20 Ma Outputs, Serial Output, Alarm
Box, Mechanical Totalizer
20. Report A Setup: Flow, DO/pH, YSI 600, Sample History,
Flow Meter History
21. Level In Report: Yes, No_______________________________
22. Flow Rate In Report: Yes, No __________________________
23. Rainfall In Report: Yes, No ____________________________
24. PH or DO In Report: Yes, No___________________________
25. Temperature In Report: Yes, No________________________
26. YSI 600 Data in Report: Yes, No _______________________
27. Sample History In Report: Yes, No _____________________
28. Flow Meter History In Report: Yes, No__________________
29. Report B Setup: Flow, DO/pH, YSI 600, Sample History,
Flow Meter History
30. Level In Report: Yes, No_______________________________
31. Flow Rate In Report: Yes, No __________________________
32. Rainfall In Report: Yes, No ____________________________
33. PH or DO In Report: Yes, No___________________________
