4210 Flow Meter
Appendix B Programming Worksheet
B-3
34. Temperature In Report: Yes, No________________________
35. YSI 600 Data in Report: Yes, No _______________________
36. Sample History In Report: Yes, No _____________________
37. Setup Options: Status, Report Setup, LCD Backlight ____
38. LCD Backlight Mode: Timeout, Continuous, Off _________
39. Language: English, ___________________________________
40. Program Lock: On, Off ________________________________
41. Select Option: Program, Setup. This time, select Program
and do the following (Program Section).
42. Units Of Level Measure: Ft., In, M, mm, Not Measured __
43. Flow Rate Units of Measure: GPS, GPM, GPH, MGD, CFS,
CFM, CFH, CFD, LPS, M3S, M3M, M3H, M3D, AFD,
44. Totalized Volume Units: GAL, MGAL, CF, L, M3, AF ____
45. Rain Gauge: Inches, MM, Not Measured ________________
46. pH Units Of Measure: pH, Not Measured _______________
47. D.O. Units: MG/L, PPM, Not Measured _________________
48. Temperature Units: Deg F, Deg. C, Not Measured _______
49. YSI-pH Units Of Measure: pH, Not Measured ___________
50. YSI-D.O. Units: MG/L, PPM, Not Measured _____________
51. YSI-Conductivity Parameter: Specific Conductivity, Salin-
ity, Conductivity, T.D. S.
________Units________Coeff._______
52. YSI-Temperature: Deg F, Deg. C, Not Measured _________
Step 2 - Flow Conversion - Level-to-Flow Rate
1. Flow Conversion Type: Weir/flume, Equation, Manning,
Data Points, _________________________________________
2. Type Of Device: Weir, Flume___________________________
3. Select Type Of Weir: V-notch, Rectangular, Cipolletti_____
4. Select V-notch Weir Angle (In Degrees): 22.5, 30, 45, 60, 90,
120,
5. End Contractions On Rectangular Weir: Yes, No_________
6. Rect. Weir With End Contractions: Enter Crest Length
___._____ Feet (or Meters)
7. Cipolletti Weir: Enter Crest Length___._____(Ft./M)
8. Type Of Flume: Palmer-Bowlus, Parshall, Trapezoidal, H,
HS, HL, Leopold-Lagco
9. Palmer-Bowlus Size: 4", 6", 8", 9", 10", 12", 15", 18", 21",
24", 27", 30", 48"
10. Parshall Size: 1", 2", 3", 6", 9", 1.0', 1.5', 2.0', 3', 4', 5', 6', 8',
10', 12’'
11. Trapez. Size: LG 60 V, 2" 45 WSC, 45 SRCRC, XL 60_____
12. Flume Size:.5',.75', 1', 2', 2.5' 3', 4.5' ____________________
13. HS Flume Size: 0.4', 0.5', 0.6', 0.8', 1.0 __________________
