4210 Flow Meter
Appendix B Programming Worksheet
B-4
14. HL Flume Size: 2.0', 2.5', 3.0', 3.5', 4.0 __________________
15. Leopold-Lagco Flume Size: 4", 6", 8", 10", 12", 15", 18", 21",
24”, 30”
16. Enter Equation Units: Q = ___.___H^___ + ___.___H^___
(Q = kH
P1
+ kH
P2
)
(Note that if your equation does not have a second term, (kH
P2
),
just enter 0 (zero) for it.)
17. Manning Types: Round Pipe, U-channel, Rectangular,
Trapezoid
18. Mann. Round Pipe: Slope = _.______Rough = _.______
19. Mann. Round Pipe: Diameter = _.___Feet (or meters)
20. Mann. U-channel: Slope = __.____Rough = __.____
21. Mann. U-channel: Width = __.____ Feet (or meters)
22. Mann. Rectangular: Slope = __.____ Rough = __.____
23. Mann. Rectangular: Width = __.____ Feet (or meters)
24. Mann. Trapezoid: Slope = __.____ Rough = __.____
25. Mann. Trapezoid: Top Width = __.____ Feet (or meters)
26. Mann. Trapez.: Bottom Width = __.____ Feet (or meters)
27. Select Data Set: One, Two, Three, Four, (None) __________
28. Level Units For Data Point Entry: Ft., In, M, Mm _______
29. Flow Rate Units: GPM, GPS, MGD, CFS, CFM, M3S,
M3H, M3D, LPS, CFD, GPH, AFD, CFH, CFM, M3M
30. Set __(1-4): (0) Points Entered: Add Point, (units) ________
31. Set 1 Data Point 1: Enter: __.____ (level units) __.____
(units of volume) (Enter data points in the table in next col-
umn. Additional tables on following pages.)
Enter Maximum Head
32. Maximum Flow: ___._____ (units of measure)____________
