4210 Flow Meter
Section 2 Programming
2-31
:Also available with the arrow key:
If you select PARSHALL for the type of flume, the following will
appear:
If you press the right arrow key several times, the sizes shown
below will move onto the screen:
If you select PALMER-BOWLUS for the type of flume, the fol-
lowing will appear:
If you press the right arrow key several times, the sizes shown
below will move onto the screen:
If you select LEOPOLD-LAGCO for flume, the following will
appear:
If you press the right arrow key several times, the sizes shown
below will move onto the screen:
If you select HS for the type of flume, the following display will
appear:
Select H for flume and the following will appear:
Select HL for flume and the following will appear:
If you select TRAPEZOIDAL for the type of flume, the following
will appear:
SELECT TYPE OF FLUME
• HS • • H • • HL • • TRAPEZOIDAL
SELECT PARSHALL SIZE:
• 1" • • 2" • • 3" • • 6" • • 9" • • 1.0' • • 1.5' • • 2.0 •
SELECT PARSHALL SIZE:
• 3' • • 4' • • 5' • • 6' • • 8' • • 10' • • 12' •
SELECT PALMER-BOWLUS SIZE
• 4" • • 6" • • 8" • • 9" • • 10" • • 12" • • 15" • • 18" • • 21 •
SELECT PALMER-BOWLUS SIZE
• 24" • • 27" • • 30" • • 48" •
LEOPOLD-LAGCO FLUME SIZE
• 4" • • 6" • • 8" • • 10" • • 12" • • 15" • • 18" • • 21" •
LEOPOLD-LAGCO FLUME SIZE
• 24" • • 30" •
HS FLUME SIZE
• 0.4' • • 0.5' • • 0.6' • • 0.8' • • 1.0' •
H FLUME SIZE
• 5' • • .75' • • 1' • • 2' • • 2.5' • • 3' • • 4.5' •
HL FLUME SIZE
• 2.0' • • 2.5' • • 3.0' • • 3.5' • • 4.0' •
TRAPEZOIDAL SIZE
• LG 60 V • • 2" 45 WSC • • 12”45 SRCRC •
