4210 Flow Meter
Section 2 Programming
2-38
If you select ABS (absolute) BAROMETRIC PRESSURE the fol-
lowing will appear:
Absolute barometric pressure is barometric pressure not
corrected to sea level. The barometric pressure published by
the U.S. Weather Bureau is corrected to sea level. If you use their
value, you must convert it to the absolute pressure for your
altitude. You should use Weather Bureau barometric pressure
only if you are at sea level, or are able to correct the Weather
Bureau figure to absolute pressure at your location. Enter the
value for barometric pressure.
Then the display will advance to the following:
If you select ALTITUDE for D.O., the following will appear:
Select the appropriate units and press Enter.
Enter the altitude for your location. Then:
For more detailed information on the pH and D. O. probes, see
Section 4.
Returning to step 3, Parameter to Adjust, the following display
will appear:
NOTE
If you are using the YSI Sonde and YSI 600 does not appear on
your display, return to step 1, Program, and make sure you have
selected YES from the YSI CONNECTED menu.
If you select YSI 600, the following display will appear:
If you select pH for the parameter to calibrate, the following
display will appear:
ABS BAROMETRIC PRESSURE
X.XX mmH
g
WRAP D. O. PROBE IN MOIST CLOTH
PRESS ENTER WHEN STABLE: X.XX MS/CM:
CALIBRATING...
PLEASE WAIT...
UNITS FOR ALTITUDE ENTRY
• FT • • M •
ALTITUDE
ALTITUDE = X.XX FT (or meters)
WRAP D. O. PROBE IN MOIST CLOTH
PRESS ENTER WHEN STABLE: X.XXX MG/L
PARAMETER TO ADJUST
• NONE • • (LEVEL) • • (pH) • • (DO) • • (YSI 600) •
YSI 600 PARAMETER TO CALIBRATE
• NONE • • pH • • DO • • CONDUCTIVITY •
YSI 600 pH CALIBRATION
• pH 4 & 7 • • pH 7 & 10 • • pH 4, 7, & 10 •
