ISHIDA WM-NANO Service Manual

Chapter 3 Adjustment Mode
5） Lift and remove the wrapping unit.
When carrying the unit, hold the outside frame
portions.
Do not hold the film arm portion on the left
lateral.
6） Rest the wrapping unit against some object or place it horizontally.
<Resting the unit against some object>
Rest the unit in the lateral direction against some
other object.
<Placing the unit horizontally>
Place the unit upside down.
NOTE:
Do not place the unit with the left lateral film arm
portion downside.
3-15
