Jadak HS-1RL - 9 - Product Specifications

HS-1RL User’s Manual Page 60
9 - Product Specifications
RFID
RF Frequency:
125 kHz (LF)
Supported
Transponders:
Cotag, G-Prox (hash value only), HID Prox, Honeywell NexWatch, Indala, ioProx,
EM4100, 4102, 4200 (UID only), AWID, CASI-RUSCO, HITAG 1 (no encryption), HITAG
2 (no encryption), HITAG S (no encryption), Keri, Miro, Pyramid, TIRIS/HDX, UNIQUE,
FDX-B, Q5, TITAN (4x50), T55x7, ZOODIAC
Antenna:
Internal
Read Range:
Contact to 1.0”+ (Tag dependent)
Barcode Scanning
Light Source:
White LED illumination, Green LED line aimer
Rotational Sensitivity:
360
o
Min X Dimension:
Linear codes: 5 mil, 2D Codes: 10 mil
Reading Distance:
2.0” to 15” (barcode dependent)
Ambient:
0-100,000 lux (complete darkness to full sunlight)
Symbologies:
2D: PDF417, MicroPDF417, Maxicode, Data Matrix, QR Code, Aztec, GS-1
Composite
Linear: Code 39, Code 128, Codabar, UPC, EAN, Interleaved 2 of 5, GS-1 Databar,
Code 93
User Interface and Software
Control/Data Interface:
USB (Keyboard or COM Port), RS-232 (available upon request)
OS Compatibility:
Windows 10, Windows 7, Linux Ubuntu, other OS available upon request
User Indicators:
2 LEDs, adjustable audio signal, and optional vibration motor
Electrical
Power Supply:
5VDC +/- 5%
Current:
500mA max. while scanning; 100mA while idle
Safety, Regulatory and
Environmental
Compliance:
FCC Class B, Industrie Canada (IC), ETSI EN 300 330 V2.1.1, RED 2014/53/EU,
CE, IEC/EN60601 4
th
edition compatible for ESD, UL testing per IEC/EN60950 2
nd
edition, 2005, Amendment 2:2013, ROHS, REACH, WEEE
Environmental
Operating Temp.:
32° F to 122° F (0° to 50°C)
Relative Humidity:
95% RH non-condensing, at +50°C
Environmental Sealing:
IP54 Sealed Housing
Recommended
Cleaning Solutions:
Sani-Cloth® HB, Sani-Cloth® Plus, Super Sani-Cloth®, Isopropyl Alcohol Wipes
(70%), Cavi-Wipes, Betadine®, 409®, Windex® Blue, Hydrogen Peroxide (3%),
Clorox® Bleach, gentle dish soap and water
All specifications subject to change without notice.
