HS-1RL User’s Manual Page 76
No option specified at this time. Always transmit 0. GS1
DataBar and GS1 DataBar Limited transmit with an Application
Identifier “01”.
Note: In GS1-128 emulation mode, GS1 DataBar is
transmitted using Code 128 rules (i.e., ]C1).
Example: A GS1 DataBar bar code 0110012345678902 is
transmitted as ]e00110012345678902.
0 No check digit processing.
1 Reader has checked check digit.
3 Reader has stripped check digit before transmission.
Example: A Codabar bar code without check digit, 4123, is
transmitted as ]F04123
0 No options specified at this time. Always transmit 0.
Example: A Code 93 bar code 012345678905 is transmitted
as ]G0012345678905
3 Check characters validated but not transmitted.
0 No check digit processing.
1 Reader has validated check digit.
3 Reader has validated and stripped check digit.
Example: An I 2 of 5 bar code without check digit, 4123, is
transmitted as ]I04123
PDF417, Macro PDF417, Micro
PDF417
0 Reader set to conform to protocol defined in 1994 PDF417
Symbology specifications.
Note: When this option is transmitted, the receiver cannot
reliably determine whether ECIs have been invoked or
whether data byte 92DEC has been doubled in transmission.
1 Reader set to follow the ECI protocol (Extended Channel
Interpretation). All data characters 92DEC are doubled.
2 Reader set for Basic Channel operation (no escape
character transmission protocol). Data characters 92DEC are
not doubled.
Note: When decoders are set to this mode, unbuffered
Macro symbols and symbols requiring the decoder to convey
ECI escape sequences cannot be transmitted.
3 The bar code contains a GS1-128 symbol, and the first
codeword is 903-907, 912, 914, 915.
4 The bar code contains a GS1-128 symbol, and the first
codeword is in the range 908-909.
5 The bar code contains a GS1-128 symbol, and the first
codeword is in the range 910-911.
Example: A PDF417 bar code ABCD, with no transmission
protocol enabled, is transmitted as ]L2ABCD.
