11
Replacing the Needle
To remove:
1. Loosen the needle clamp screw.
2. Remove the needle.
To attach:
3. Insert the needle into the needle clamp with the long
groove facing you. Push the needle up as far as it will
go.
4. Tighten the needle clamp screw.
Needle clamp screw
Needle
Long groove
Needle and Thread Reference Table
Use DBxK5Q1NY needles and select an appropriate size of
needle for threads and fabrics to be sewn.
An inappropriate size of needle may cause skip stitches,
thread breakage or loose seam.
Please refer to the table below and select the
suitable needle size.
75 8 to10
120 9 to 11
200 11 to 14
Thread Size (Denier)
Polyester
Needle Size
To Next Page
