JLG E450A - Cartridge Torque Values

SECTION 5 - BASIC HYDRAULIC INFORMATION & SCHEMATICS
3121714 5-141
1001097775-C
MAE32380C
2
1, A
Table 5-38. Cartridge Torque Values
Ft. Lbs. Nm
125 34
220 27
Table 5-39. Coil Torque Values
Ft. Lbs. Nm
A5 7
Figure 5-155. Jib Valve Torque Specification (SN 0300208529 through 0300233452, SN B300001429 through B300002532)
