SECTION 3 - CHASSIS & TURNTABLE
3-8 3121714
FC-1 48V B+
(20A)
FC-3 OPTION FUSE
(5A)
FC-2 12V SYSTEM
(15A)
FC-601 DELTA Q
(30A)
NOTE: CHARGER FUSE SHOULD BE IN PLACE.
Figure 3-6. System Fuses
