SECTION 3 - CHASSIS & TURNTABLE
3121714 3-59
1. AC Voltage - Input Cable 2. Battery Charge Signal Cable 3. DC Power Cable to Batteries
Figure 3-31. Battery Charger (E450A/AJ)
