OP JIB DOWN OPEN or CLOSED (advanced test after switch toggles)
CL JIB SWING LEFT OPEN or CLOSED (advanced test after switch toggles)
OP JIB SWING LEFT OPEN or CLOSED (advanced test after switch toggles)
CL JIB SWING RIGHT OPEN or CLOSED (advanced test after switch toggles)
OP JIB SWING RIGHT OPEN or CLOSED (advanced test after switch toggles)
CL PATFORM LEFT OPEN or CLOSED (advanced test after switch toggles)
OP PLATFORM LEFT OPEN or CLOSED (advanced test after switch toggles)
CL PLATFORM RGHT OPEN or CLOSED (advanced test after switch toggles)
OP PLATFORM RGHT OPEN or CLOSED (advanced test after switch toggles)
CL PLATFORM UP OPEN or CLO SE D ( adv an ce d t es t a fte r swit ch to gg les )
OP PLATFORM UP OPEN or CLOSED (advanced test after switch toggles)
CL PLATFORM DOW N O PEN or CLO SE D ( adv an ce d t es t a fte r swit ch to gg le s)
OP PLAT FO RM DOWN OP EN or CLO SE D ( adv an ce d t es t a fte r swit ch to gg le s)
CL FUNC ENABLE O PE N o r C LO SE D ( ad va nc ed te st af ter swit ch t og gl es)
OP FUNC ENABLE OP EN or CLO SE D (adv an ce d te st af ter swit ch t og gl es)
CL MSSO SWITCH OPEN or CLOSED (advanced test after switch toggles); display only if MACHINE SETUP ' MARKET =
CE
OP MSSO SWITC H O PEN or CLO SE D ( adva nc ed te st af te r s wi tc h to gg le s) ; d is play on ly if MA CH IN E S ET UP ' MAR KE T =
CE
TESTING PL ATF OR M L AM PS B AT F ULL LAM P ON
BAT 3/4 LAMP ON
BAT 1/2 LAMP ON
BAT 1/4 LAMP ON
LOW BATTERY
ENABLE LAMP ON
CREEP LAM P ON
DISTRESS LAMP ON
TILT LAMP ON
OV ER LOAD L AM P O N D i sp lay o nl y i f L SS co nf ig ure d
DRIVE ORIENTATION LAMP ON
SKYGUARD LAMP ON Display on if SkyGuard configured
SOFTTOUCH Display if Soft Touch configured
PLAT ALARM ON
HORN ON
TESTING GROUND LAMPS OVERLOAD LAMP ON Display only if MACHINE SETUP ' MARKET = CE
ALERT BEACON Display only if MACHINE SETUP-> ALERT BEACON = 20FPM FOR CREEP
TESTS COMPLETE Indicates that the system test is complete. Any problems reported should have been noted and
s ho ul d n ow be re ctifie d. Pr es s E SC /C A NC EL to return to the RUN SYSTEM TEST Analyzer menu.
Table 6-11. System Test Messages
Message Displayed on
Analyzer
Message Displayed on
Analyzer
Description
