SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3121813
1.7 FUNCTION SPEEDS
Machine Orientation When Doing Speed
Tests
Lift: Boom Retracted. Telescope Retracted. Lift Up,
Record Time, Lift Down, Record Time.
Swing: Boom at Full Elevation. Telescope Retracted.
Swing the Turntable to the end stop. Swing the Opposite
Direction, Record Time.
Te l e s co pe: Boom at Full Elevation; Telescope Retracted;
Telescope Out, Record Time. Telescope In, Record Time.
Drive: Test to be done on a smooth level surface. Start
approximately 25 ft. (7.62 m) from starting point so that
the unit is at maximum speed when starting the test.
Results should be recorded for a 200 ft. (60.96 m) course.
Drive Forward, record time. Drive Reverse, Record Time.
Drive (Above Horizontal): Test should be done on a
smooth level surface. The Platform Speed Knob should be
selected out of the creep speed. This verifies that the
switches are working when the boom is above horizontal.
Results should be recorded for a 50 ft. course. Drive For-
ward, Record Time. Drive Reverse, Record Time.
Platform Rotate: Platform level and completely rotated
one direction. Rotate the opposite direction, Record Time.
Rotate the other direction, Record Time.
Articulating Jib: Platform level and centered with the
boom. Start with the Jib down. Jib Up, Record Time. Jib
Down, Record Time.
Test Notes
1. Stop watch should be started with the function, not
with the controller or switch.
2. Drive test results reflect 36/14LL-22.5 tires.
3. All speed tests are run from the platform. These
speeds do not reflect the ground control operation.
4. The platform speed knob control must be at full
speed (turned clockwise completely).
5. Function speeds may vary due to cold, thick hydrau-
lic oil. Test should be run with the oil temperature
above 100° F (38° C).
6. Some flow control functions may not work with the
speed knob clicked into the creep position.
1.8 PRESSURE SETTINGS
Table 1-7. Function Speeds
Lift Up 55-61
Lift Down 55-61
Swing Right & Left 72-84
Telescope Out 46-50
Telescope In 46-50
Platform Rotate Left & Right 24-26
Jib Up 25-27
Jib Down 21-23
Jib Swing 30-40
High Drive (200 ft.) 42-46 (3.0 mph)
Drive above Horizontal (50 ft.) 65-71 (0.5 mph)
4150273-N
Table 1-8. Pressure Settings
SETTING PSI BAR
Proportional Main Relief 3200 220
Bang Bang Main Relief 3000 207
Lift Up 2500 172
Lift Down 1100 76
Swing 2500 172
Swing Brake 320 22
Steer 1800 124
Platform Level Up 2500 172
Platform Level Down 1500 103
Jib Up 2300 158.5
Jib Down 2300 158.5
