SECTION 6 - JLG CONTROL SYSTEM
6-12 – JLG Lift – 3121813
6.8 MACHINE CONFIGURATION
PROGRAMMING INFORMATION
Table 6-3. Machine Configuration Programming Information
Configuration Digit Number Description
Default
Number
1
MODEL #
1
2
E600
M600
1
2
TILT SENSOR
1
2
3
4
When tilted the tilt light is lit (continuously) and drive speed is reduced to the creep speed setting
5 degree - reduces the maximum speed of all platform functions to creep when tilted and
above elevation. Reduces drive speed to creep when tilted. (Domestic/Japan)
4 degree - reduces the maximum speed of all platform functions to creep when tilted and above
elevation. Reduces drive speed to creep when tilted. (European/Australian)
4 degree - cuts out drive and reduces boom functions to creep speed when tilted and above ele-
vation. Reduces drive speed to creep when tilted only. (Option)
3 degree - reduces the maximum speed of all boom functions to creep when tilted and above
elevation. Reduces drive speed to creep when tilted. (CE and Australian E600JP, M600JP)
NOTE: Any of the selections above will light the tilt lamp when a tilted condition
occurs and will sound the platform alarm when the machine is tilted
and above elevation.
1
3
DRIVE CUTOUT
0
1
2
Battery Charger Cutout - cuts out drive when the battery charger is plugged in
Battery Charger Cutout and Simultaneous Drive and Boom functions disabled above elevation
(European/Australian)
Battery Charger Cutout and Drive Cutout above elevation (Option)
0
4
FUNCTION
CUTOUT LIMIT
SWITCH
0
1
2
0= No Function Cutout
1= Cuts out all boom functions when switch opens (Option)
2= Cuts out all functions when the switch opens (Option)
0
5
JIB
0
1
2
No jib installed
Jib installed which has up and down movements only (Option)
Jib installed which has up and down movements and side to side movements
(Option)
0
6
GROUND
ALARM
0
1
2
3
No ground alarm installed
Travel Alarm - Sounds when the drive function is active (Option)
Descent Alarm - Sounds when either lift down is active (Option)
Motion Alarm - Sounds when any function is active (Option)
0
