SECTION 6 - JLG CONTROL SYSTEM
3121813 – JLG Lift – 6-9
6.7 MACHINE PERSONALITY SETTINGS
NOTE: Personality settings can be adjusted within the
adjustment range in order to achieve optimum
machine performance.
Table 6-2. Personality Ranges/Defaults
FUNCTION PERSONALITY RANGE DEFAULTS
DRIVE ACCELeration 0.5s to 5.0s 1.0
DECELeration 0.1s to 2.0s 0.5
MINimum speed 0 to 25% 3
MAXimum speed 0 to 100% 72
ELEVATED MAXimum speed 0 to 25% 12
CREEP MAXimum speed 0 to 45% 30
POSITRAC time 0 to 60s 10
POSITRAC current 50-400 A 300A
4WD MINimum 0 to 50% 20
4WD MAXimum 0 to 100% 50
4WD Cutback 0 to 50% 30
LIFT ACCELeration 0.5 to 5.0 0.7
DECELeration 0.1 to 3.0 1.0
MlNimum UP speed 0 to 20% 8
MAXimum UP speed 0 to 100 85
CREEP Maximum UP speed 0 to 50 25
MINimum DOWN speed 0 to 10 1
MAXimum DOWN speed 0 to 100 53
CREEP maximum DOWN speed 0 to 30 15
SWING ACCELeration 0.5 to 5.0s 0.7
DECELeration 0.1 to 3.0s 1.5
MINimum LEFT speed 0 to 10% 1
MAXimum LEFT speed 0 to 60% 6
CREEP maximum LEFT speed 0 to 35% 4
MINimum RIGHT speed 0 to 10% 1
MAXimum RIGHT speed 0 to 60% 6
CREEP maximum RIGHT speed 0 to 35% 4
