JLG E600 - Generator

SECTION 3 - CHASSIS & TURNTABLE
3-60 – JLG Lift – 3121813
7
13
10
12
11
8
9
7
12
10
5
13
3
6
2
1
4
Figure 3-35. Generator
8. Temperature Sensor
9. Voltage Regulator
10. Alternator
11. Starter
12. Starter Solenoid
13. Oil Filter
1. Glow Plug Relay
2. Fuel Control Relay
3. Start Control Relay
4. Fuel Solenoid
5. Fuel Filter
6. Low Oil Pressure Switch
7. Glow Plug
