SECTION 6 - JLG CONTROL SYSTEM
3121813 – JLG Lift – 6-17
2/5 Flash code 2/5 indicates that a function is prevented due to a cutout.
BOOM PREVENTED - DRIVE SELECTED
A boom function is selected while a drive function is selected and drive cutout is configured to prevent simultaneous drive & boom
operation.
BOOM PREVENTED - FUNCTION CUTOUT ACTIVE
A b oom fun cti on i s selected w hile f unc tio n cu tout is active an d co nfi gur ed to cut out boo m functi ons.
DRIVE & BOOM PREVENTED - FUNCTION CUTOUT ACTIVE
Drive or a boom function is selected while function cutout is active and configured to cutout all functions.
DRIVE PREVENTED - ABOVE ELEVATION
Drive is selected while above elevation and drive cutout is configured to prevent drive.
DRIVE PREVENTED - BOOM MOVEMENT SELECTED
Drive is selected while a boom function is selected and drive cutout is configured to prevent simultaneous drive & boom operation.
DRIVE PREVENTED - CHARGER CONNECTED
Drive is selected while the charger is on (indicated by drive cutout being active) and drive cutout is configured to prevent drive.
DRIVE PREVENTED - TILTED & ABOVE ELEVATION
Drive is selected while tilted and above elevation and tilt is configured to cutout drive.
3/1 Flash code 3/1 indicates that a contactor did not close when energized.
LINE & DIRECTION CONTACTORS MISWIRED
When the line contactor was closed traction point A went high (and the capacitor bank charge did not increase to battery supply) - this
occurs if the line contactor coil wiring is swapped with that for a direction contactor coil.
OPEN-CIRCUIT FORWARD CONTACTOR OR TRACTION MOTOR
Traction point A did not go high when forward contactor was energized (this could be due to traction motor open-circuit or a power wir-
ing error).
OPEN-CIRCUIT LINE CONTACTOR
The capacitor bank charge did not increase to battery supply when line contactor was energized (this could be due to a power wiring
error).
OPEN-CIRCUIT REVERSE CONTACTOR OR TRACTION MOTOR
Traction point A did not go high when reverse contactor was energized (this could be due to traction motor open-circuit or a power wir-
ing error).
3/2 Flash code 3/2 indicates that a contactor did not open when deenergized.
WELDED LINE CONTACTOR
The capacitor bank charge did not decrease from battery supply when line contactor was deenergized (this could be due to a power
wiring error).
WARNING: If the line contactor is welded, the controller will not switch off when EMS or keyswitch is turned off.
Table 6-5. Help Descriptions and Fault Flash Codes
