SECTION 6 - JLG CONTROL SYSTEM
6-26 – JLG Lift – 3121813
FSW1 … Displays footswitch status
NOTE: FSW1 is wired to the power module
FSW2 … Displays footswitch status
NOTE: FSW2 is wired to the platform module
DRIVE CUTOUT … Displays drive cutout switch status
ELEV. CUTOUT … Displays elevation cutout switch status
FUNC. CUTOUT … Displays function cutout switch status
BRAKES … Displays brake pressure switch status
MAN.RELEASE … Displays manual brake release switch status
TILT … Displays measured vehicle tilt
The first value indicates tilt in the forward/ reverse direction (pitch)
The second value indicates tilt in the left/ right direction (roll)
DATALOG
MAX.TEMP … Displays maximum measured heatsink temp.
MIN.TEMP … Displays minimum measured heatsink temp.
MAX.BATTERY … Displays maximum measured battery voltage
ON … Displays total controller on (EMS) time
DRIVE … Displays total controller drive operation time
PUMP … Displays total controller pump running time
NOTE: includes all boom functions, steer and brake release
LIFT … Displays total controller lift operation time
SWING … Displays total controller swing operation time
TELE … Displays total controller tele operation time
RENTAL … Displays total controller operation time
NOTE: can be reset
ERASE RENTAL Not available at password level 2
YES:ENTER, NO:ESC ENTER resets rental datalog time to zero
VERSIONS
POWER … Displays power module software version
PLATFORM Displays platform module software version
GROUND Displays ground module software version
POSITILT Displays positrac/tilt module software version
ANALYSER … Displays Analyzer software version
Table 6-7. Diagnostic Menu Descriptions
