SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION
31217162 2-11
3. With the platform in the stowed position:
a. Drive the machine on a grade, not to exceed the rated
gradeability, and stop to ensure the drive motor brakes
hold.
b. Check the tilt indicator light to ensure proper opera-
tion. The light should be illuminated if tilted beyond
allowed settings in Table 2-2.
Table 2-2. Tilt Cutout Settings
Model
Lift Up and Drive prevented when
elevated and tilted Front to Back
beyond the following limits:
Lift Up and Drive prevented
when elevated and tilted Side to
Side beyond the following limits:
RT2669, ERT2669 3°
4.0° at 0% - 55% Capacity
3.0° at 56% - 75% Capacity
2.5° at 76% - 100% Capacity
RT3369, ERT3369 3°
3.5° at 0% - 35% Capacity
3.0° at 36% - 55% Capacity
2.5° at 56% - 100% Capacity
