13
Lead 2 (low side) Microswitch for W.G.
Lead 1 (+5V) micro switch wheel guard
X2 Motor wires
Capacitor CO
Power supply
X8 Offset potentiometer
X7 Diameter potentiometer
X4 Optoencoder, sonar
transducers, weight laser
board
Lead 4 (OW side) pedal switch push
Lead 3 (+5V) for pedal switch push
Lead 2 (OW side) pedal switch pull
Lead 1 (+5V) for pedal switch pull
F1 and F2 Fuses
X3 Power clamp-when
available
Capacitor CT
