E10 Sape Out During wheel spin
Complaint After the lowering the wheel guard, the balancer does not spin the wheel and E10 comes up.
Root cause Gauge arm removed from idle position during wheel spin.
Service Code C80, C81, C82, C115, C84, C88,
Actions to do
Reposition SAPE arm in home position and press STOP or ESC key to continue.
Calibrate the distance potentiometer.
Re-connect the distance potentiometer to the Integrated Display.
Replace the distance potentiometer
Replace the Integrated Display.
E11 Gauge arm not in home position
Complaint After turning on the balancer show E11.
Root cause
Inner SAPE gauge arm not in home position.
Weight tray not properly placed.
Distance potentiometer not calibrated.
Distance potentiometer disconnected from the Integrated Display.
Difective distance potentiometer cable.
Defective distance potentiometer.
Defective Integrated Display.
Service Code C92, C80, C81, C115, C84, C88
Actions to do
Reposition SAPE gauge arm in home position and press STOP or ESC key to continue.
Replace the weight tray.
Calibrate the distance potentiometer.
Re-connect the distance potentiometer to the Integrated Display.
Replace the distance potentiometer
Replace the Integrated Display.
E14 The power clamping device is not clamped
Complaint At the end of the wheel clamping, the balancer shows E14.
Root cause Incorrect wheel clamping
Service Code
Actions to do
Check the cone
Check the shfat
Check the clamping sleeve
Clamp the wheel again
E21 Power Clamp Locked
Complaint Pushing the pedal the shaft rotates for a while and the display shows E21
Root cause Main shaft not hold in place during clamping/unclamping
Service Code C56, C74, C98, C115, C84, C88, C122,
Actions to do
Check the Power Clamp pedal.
Check the brake pads
Check the electromagnetic brake
Check the drive Pulley Optoencoder
Check the main shaft Optoencoder.
Check the Integrated board
