C55 Indication of the line voltage
Options: None
Special function: None
Description: Indication of line voltage
Comments: Please refer to error ID 800, 801, 804 for the limits.
C56 Indication of the circuit state of the wheel guard switch
Options None
Special function: None
Description: The wheel guard switch is assigned to the hundreds digit, the micro-switch actuated by depressing
the pedal to the tens digit and the micro-switch actuated by lifting the pedal to the units digit. This test function can be
used to determine the angle at which the wheel guard switch trips.
0 : off (released)
1 : on (activated)
0/1 0/1 0/1
Switch wheel guard Depress pedal Switch
Comments: If the wheel guard switch remain to 0, before replacing it check also the low end switch of the wheel lift
because they are connected in serial.
After exit C56, turn off and on again the balancer to enable the pedal control.
C57 Indication of the temperature
Options: None
Special function: None
Description: Indication of temperature in centigrade (°C)
Comments: Please refer to error ID 580, 581, 585, 586 for the limits.
C59 Indication of the residual unbalance of main shaft compensated for using C84
Options: None
Special function: None
Description: Indication of the residual unbalance of the main shaft and drive pulley compensated for using C84
Channel 1 corresponds to front transducer
Channel 0 corresponds to rear transducer
Maximum unbalance allowed:
Comments: None
C60 Indication of RPM of main shaft
Options: None
