96
Front transducer: 25-135
Comments: The shown values are those ones calculated in the latest calibration performed.
C66 Display calibration values as measured with C code 83/115 (virtual dimensions)
Options: None
Special function: None.
Description: Values for both transducers in mm. Reference mark is the zero reference of Geodata
Values for both transducers in mm.
Reference mark is the zero reference of Geodata (right-hand edge of machine cabinet for geodata)
1. Field : Rear transducer: 262 - 272
2. Field : Front transducer: -1500 to -10000
Comments: The shown values are those calculated in the latest calibration performed.
C67 Display phase stability of the vpm system as measured with C code 83/115
Options:
Press “RETURN” key to switch over between
- the distance-dependant phase shift of the rear transducer and
- the phase shift between the rear and front transducers
Special function: None.
Description: The distance-dependant phase shift of the rear transducer is indicated ! rst.
Comments: The shown values are those calculated in the latest calibration performed,
C69 Successive measuring runs with pauses
Options.
In step 1:
0 to 50 : First pause, which simulates the weight application (init value = 50 seconds).
In step 2:
0 to 170 : Second pause, which simulates the (un)clamping of the wheel (init value = 170 seconds)
In step 3: Only models with power clamp
0 : Do not unclamp/clamp the wheel
1 : Unclamp/Clamp the wheel after the second pause.
Special function: please refer to the service function C63
Description:
Mount an unbalanced wheel on the shaft.
Displayed values and usage of this service function is the same as service code 63, with the except of the pauses and
the unclamp/clamp cycle.
Comments: None
C71 Display angular deviation of VPM system as measured with C code C83 / C115
Options: Press “RETURN” key to switching over between rear and front transducers
Special function: None.
Description: Reading on display machine must be:
