SECTION 24 – BURNER INSTALLATION (WEISHAUPT BURNERS)
FORM 155.17-N1
ISSUE DATE: 4/1/2013
Regulation Type – YORK uses the following regula-
tion type on the ParaFlowTM chiller/heaters:
ZM = Gas, modulating or oil modulating
ZMA = Gas, modulating, high turn-down
ZMI = Gas, modulating, very high turn-down
Electrical Power Supply = “D” indicates three-phase
The installation, start-up, or servicing of
any Weishaupt burner or any equipment
sup plied by Weishaupt must only be car-
ried out by fully qualied and licensed
person(s). The person(s) performing the
work must be fa mil iar with, and operate
within, the ap pli ca ble local and national
codes.
FIELD WIRING
Due to the fact that the burner swings open for ser vice
(either right or left), flexible conduit must be used for
the last 5 to 6 feet before the burner. Do not use rigid
conduit right up to the burner! A wiring diagram is
provided with all burners. A separate page titled “Con-
nection Diagram” is included, which rec om mends and
illustrates the number of conduits for the field wiring,
including the number of wires for each con duit.
It is recommended that the ame scan-
ner wires are run in a separate conduit
and not in multi-wire ca bles. Maximum
line length for UV monitoring is 97 feet
(30 meters). For de tails re fer to the ame
safe guard man u al.
Swinging Open The Burner
If it becomes necessary to open the burner, please fol-
low the below instructions:
1. Disconnect the linkage from the servomotor to the
gas buttery valve.
2. Remove the burner top cover.
3. Disconnect the ignition and ame sensor plugs (if
ap pli ca ble).
4. Remove the lock nut and washer, which secures
the burner closed.
5. Swing the burner open carefully.
Closing The Burner:
1. Swing the burner closed. Take care not to trap the
ignition and ame sensor plugs or wires (if appli-
cable) when closing the burner.
2. Secure the burner closed with the locking nut and
wash er.
3. Remove the burner top cover to connect the igni-
tion and ame sensor plugs (if applicable).
4. On combination gas/oil burners, re-connect the
in ter nal oil lines if they have been disconnected.
5. Replace the top cover and secure.
6. Connect the linkage from the servomotor to the
gas buttery valve.
