JOHNSON CONTROLS
87
A
FORM 155.17-N1
ISSUE DATE: 4/1/2013
TABLE 3 - UNIT WEIGHTS AND DIMENSIONS
MODEL
UNIT
OVERALL DIMENSIONS
(FEET-INCHES)
MAINT.
CLEARANCE
(FEET-INCHES)
(EITHER END)
APRROX. SHIPPING WEIGHT
(LBS.)
APPROX.
OPER.
WEIGHT
LENGTH WIDTH HEIGHT W/O CHARGE W/ CHARGE
DIRECT-FIRED UNITS
12SC 14 - 1/4 6 -10 7 - 5-9/16 10-7 17,400 19,800 20,900
13SC 14 - 1/4 6 - 11-1/8 7 - 5-9/16 10 - 7 19,300 22,000 23,400
14SC 16 -7-7/8 6 -8-1/8 7 - 7-7/16 13 - 2-1/2 22,000 25,200 26,700
15SL & 16S 17-4-15/16 8 -3-3/4 9 - 1-5/16 13 - 2-1/2 32,600 36,325 38,705
16SL & 17S 20 - 8-5/16 8 - 9-9/16 9 - 2-13/16 16 - 5-7/8 39,900 44,440 47,535
18S 23 - 11-11/16 9-3/8 9 - 10 19 - 9-1/4 46,300 51,750 55,475
19S 27 - 3-1/16 9 - 3/8 9 -10 24 -5/8 54,800 61,145 65,455
STEAM-FIRED UNITS
14SC 16 - 8-1/16 6 -1-13/16 7-7-9/16 13 -2-1/2 20,900 22,500 24,300
16SL 20 - 8-5/16 7 - 7-3/4 9 - 6-7/8 16 - 5-7/8 30,200 34,150 37,800
17S 20 - 8-5/16 7 - 7-3/4 9 - 6-7/8 16 - 5-7/8 31,000 34,950 38,600
18S 23 - 11-11/16 7 - 8 10 - 3-13/16 19 - 9-1/4 36,900 41,600 45,800
19S 27 - 3-1/16 7 - 8 10 - 4-11/16 23 - 5/8 44,500 49,600 54,900
Notes:
1. Overall dimensions are for units with compact water boxes and victaulic couplings on the water nozzles.
2. If chiller has anges on the water nozzles, add 1/2" to each end for overall length.
3. Marine water boxes with anges will add height, length, and width to the unit dimensions. For details, see the appropriate Johnson Con-
trols publication as listed at the beginning of this document.
TABLE 4 - PARAFLOW™ TYPICAL CHARGES
UNIT
MODEL
REFRIGERANT SOLUTION
ALCOHOL
STEAM DIRECT-FIRED STEAM DIRECT-FIRED
DRUMS LBS. GALS. DRUMS LBS. GALS. DRUMS LBS. GALS. DRUMS LBS. GALS. GALS.
12SC N/A N/A N/A 3 1100 132 N/A N/A N/A 8 2975 221 14.3
13SC N/A N/A N/A 3 992 119 N/A N/A N/A 10 3718 276 14.3
14SC 4 1475 177 3 1300 156 9 3352 249 12 4483 333 14.3
15SL N/A N/A N/A 5 2200 264 N/A N/A N/A 13 5226 388 9.5
16S N/A N/A N/A 5 2200 264 N/A N/A N/A 13 5226 388 9.5
16SL 7 2792 335 6 2459 295 13 5072 377 17 6593 490 14.3
17S 7 2792 355 6 2459 295 13 5072 377 17 6593 490 14.3
18S 7 3034 364 7 2967 356 16 6174 458 20 7916 588 14.3
19S 9 3959 475 8 3451 414 18 6924 514 23 9217 684 19.0
NOTES: * BZT (Benzotriazole) is supplied with the chiller from the factory as part of the chiller’s ship loose parts. It is for a one time only
installation by a qualied Johnson Controls Service Technician in the rst stage generator of steam red units at chiller start-up.
One gallon of water at 60°F = 8.334 lbs.
One gallon of solution at 55% concentration = 13.48 lbs.
One drum holds 30 US gallons. Drum quantities are full drums, in some cases overage may occur.
APPENDIX A - TABLES
