TABLE 16 - ABSORPTION INSULATION LEGEND
HOT
INSULATION
INTERMEDIATE
INSULATION
COLD
INSULATION
MATERIAL 3 LB. DENSITY FIBERGLASS 2 LB. DENSITY FIBERGLASS CLOSED-CELL FOAM
THICKNESS 2 INCHES 1 INCH 3/4 INCH
COLOR
CODE ON
INSULATION
DIAGRAMS
TABLE 17 - YORK PARAFLOW™ ABSORPTION
CHILLER INSULATION AREA (SQ.
FEET)
UNIT
MODEL
DIRECT-FIRED STEAM-FIRED
HOT COLD HOT COLD
12SC 172 86
13SC 194 86
14SC 258 118 258 118
15SL 355 140
16S 355 140
16SL 398 172 398 172
17S 398 172 398 172
18S 474 205 474 205
19S 506 237 506 237
INSULATION METHODS TO AVOID:
1. Do not insulate moving parts, such as valve handles.
2. Do not insulate thermowells.
3. Do not cover sight glasses with insulation.
4. Do not cover pipe connections, since they must be accessible
for pressure and vacuum tests.
5. Do not cover pump motors with insulation.
6. Do not use weld pins to attach insulation.
TABLE 18 - YORK PARAFLOW™ ABSORPTION
CHILLER INSULATION AREA (SQ. ME-
TERS)
UNIT
MODEL
DIRECT-FIRED STEAM-FIRED
HOT COLD HOT COLD
12SC 16.0 18.0
13SC 18.0 8.0
14SC 24.0 11.0 25.0 11.0
15SL 33.0 13.0
16S 33.0 13.0
16SL 37.0 16.0 37.0 16.0
17S 37.0 16.0 37.0 16.0
18S 44.0 19.1 44.0 19.1
19S 47.0 22.0 47.0 22.0
PROPER INSULATION PRACTICES:
1. Insulation on pumps, valves, sight glasses equipment and
ange sections should be mounted so that it can be removed
easily.
2. Water boxes or cover plates must be removed/opened from
time to time for tube cleaning. Valves, pumps and nozzles
must be accessible for servicing and operation.
3. Insulate auxiliary and instrument piping by wrapping glass
wool around it.
To mount insulation materials, use
bonding agents, wires or bands. These
methods do not penetrate the chiller
system and jeopardize the integrity of
the vacuum pressure in the chiller.
WELD PINS ARE NOT ACCEPTABLE.
APPENDIX C - INSULATION ILLUSTRATIONS
