APPENDIX A - TABLES
FORM 155.17-N1
ISSUE DATE: 4/1/2013
TABLE 5 - CHILLER TUBE VOLUMES
UNIT
MODEL
TUBE SIDES
#OF
TUBES
EVAPORATOR
# OF
TUBES
ABSORBER
# OF
TUBES
CONDENSER
W/O WATER
BOXES
W/WATER
BOXES
W/O WATER
BOXES
W/WATER
BOXES
W/O WATER
BOXES
W/WATER
BOXES
GAL LTR GAL LTR GAL LTR GAL LTR GAL LTR GAL LTR
12SC 502 43.6 165.1 47.9 181.4 405 57.4 217.3 63.2 239.3 140 19.8 75.0 21.8 82.5
13SC 502 43.6 165.1 47.9 181.4 405 35.2 133.3 38.7 146.5 140 19.8 75.0 21.8 82.5
14SC 502 54.5 206.3 59.9 226.8 405 43.9 166.2 18.3 182.9 140 24.8 93.9 27.3 103.4
15SL 366 70.8 268.1 77.9 294.9 525 135.5 513.0 149.0 564.1 160 41.3 156.4 45.4 171.9
16S 408 79 299.1 86.9 329.0 525 135.5 513.0 149.0 564.1 160 41.3 156.4 45.4 171.9
16SL 366 88.5 335.1 97.4 368.8 525 169.4 641.4 186.3 705.4 160 51.6 195.4 56.8 215.1
17S 408 98.7 373.7 108.6 411.2 525 169.4 641.4 186.3 705.4 160 51.6 195.4 56.8 215.1
18S 408 118.4 448.3 130.3 493.3 525 203.2 769.4 223.6 846.6 160 61.9 234.4 68.1 257.8
19S 408 138.2 532.3 152.0 575.5 525 237.1 897.7 260.8 987.5 160 72.3 273.7 79.5 301.0
NOTE: Water boxes are compact design.
TABLE 6 - POWER FLAME ABSORPTION BURNER SIZES
UNIT
MODEL
NOM.
TONS
BURNER SIZE
MAX FIR-
ING RATE
(MBH)
MIN. FIR-
ING RATE
(MBH)
MAX OIL
FLOW
(GPH)
GAS PRESS
REQUIRED
(W.C) MIN/
MAX
SEPARATE DRIVEN OIL
PRESSURE PUMP
MOTOR
HP
SUCTION
CAPACITY
(GPH)
“S” UNITS
12SC / 13S 200 CR2-G(O)-20B 2,553 750 22 4.8 / 14 1/3 40
13SC / 14S 230 CR3-G(O)-20 2,891 900 26 5.9 / 14 1/2 105
14SC / 15S 300 CR3-G(O)-25 3,613 900 33.7 7.0 / 14 1/2 105
15SL 350 CR4-G(O)-25 4,508 1300 45 8.0 / 14 3/4 135
16S 400 CR4-G(O)-25 5,010 1300 45 8.0 / 14 3/4 135
16SL 440 CR4-G(O)-25 5,634 1300 45 8.0 / 14 3/4 135
17S 485 CR4-G(O)-25 6,261 1300 45 8.0 / 14 3/4 135
18S 580 CR4-G(O)-30 7,230 2459 56 12.1 / 14 3/4 135
19S 675 CR5-G(O)-30 8,765 3000 75 19.9 / 28 1 250
16G 400 CR4-G(O)-25 5,950 1300 45 8.0 / 14 3/4 135
16GL 450 CR4-G(O)-25 6300 1300 45 8.0 / 14 3/4 135
17G 500 CR4-G(O)-30 7,258 2459 56 12.1 / 14 3/4 135
18G 600 CR5-G(O)-30 8,936 3000 75 19.9 / 28 1 250
19G 700 CR5-G(O)-30 10,418 3000 75 19.9 / 28 1 250
19GL 800 CR5-G(O)-30 10,418 3000 75 19.9 / 28 1 250
20G* 1000 CR4-G(O)-30 7,258 2459 56 12.1 / 14 3/4 135
21G* 1250 CR5-G(O)-30 8,936 3000 75 19.9 / 28 1 250
22G* 1500 CR5-G(O)-30 10,418 3000 75 19.9 / 28 1 250
NOTES: Units equipped with two burners
This information is of a general nature only. Please refer to “Burner As Built Data” (supplied with burner) for specic job details.
