JOHNSON CONTROLS
92
APPENDIX A - TABLES
FORM 155.17-N1
ISSUE DATE: 4/1/2013
TABLE 14 - ELECTRICAL DATA - DIRECT-FIRED UNITS
CHILLER
MODEL
VOLTAGE
MAX. DUAL ELEMENT FUSE
(CUSTOMER SUPPLIED)
TOTAL UNIT AMPACITY
MINIMUM CIRCUIT
AMPACITY
SOLUTION
PUMP
REFRIGERANT
PUMP
PURGE PUMP
SOLUTION
SPRAY PUMP
#1
SOLUTION
SPRAY PUMP
#2
MICRO & POWER
PANELS
BURNER TYPE
DUAL
FUEL
DUAL
FUEL
LOW
NOX
GAS
ONLY
GAS
ONLY
LOW
NOX
DUAL
FUEL
DUAL
FUEL
LOW
NOX
GAS
ONLY
GAS
ONLY
LOW
NOX
DUAL
FUEL
DUAL
FUEL
LOW
NOX
GAS
ONLY
GAS
ONLY
LOW
NOX
FLA FLA FLA FLA FLA FLA
12SC
200/208-3-60 70 70 60 70 43.3 47.3 41.3 45.3 48.8 52.8 46.8 50.8 22.0 6.2 1.7 n/a n/a 5.0
230-3-60 60 60 60 60 39.0 42.6 37.2 40.8 44.0 47.6 42.2 45.8 20.0 5.6 1.5 n/a n/a 4.3
380-3-50 35 35 30 35 21.2 22.9 20.4 22.0 24.0 25.7 23.2 24.8 11.2 3.1 0.9 n/a n/a 2.6
460-3-60 30 30 30 30 19.6 21.4 18.7 20.5 22.1 23.9 21.2 23.0 10.0 2.8 0.8 n/a n/a 2.2
13SC &
14SC
200/208-3-60 70 70 70 70 45.7 49.7 43.1 47.1 51.2 55.2 48.6 52.6 22.0 6.2 1.7 n/a n/a 5.0
230-3-60 60 60 60 60 41.2 44.8 38.8 42.4 46.2 49.8 43.8 47.4 20.0 5.6 1.5 n/a n/a 4.3
380-3-50 35 35 35 35 22.2 23.8 21.1 22.8 25.0 26.6 23.9 25.6 11.2 3.1 0.9 n/a n/a 2.6
460-3-60 30 30 30 30 20.7 22.5 19.5 21.3 23.2 25.0 22.0 23.8 10.0 2.8 0.8 n/a n/a 2.2
15SL &
16S
200/208-3-60 90 100 90 90 63.5 67.5 60.2 64.2 70.4 74.4 67.1 71.1 27.6 13.8 1.7 n/a n/a 5.0
230-3-60 80 90 80 80 56.8 60.4 53.7 57.3 63.1 66.7 60.0 63.6 25.0 12.0 1.5 n/a n/a 4.3
380-3-50 50 50 45 50 31.8 33.4 30.4 32.0 35.6 37.2 34.2 35.8 15.0 7.0 0.9 n/a n/a 2.6
460-3-60 40 45 40 40 28.5 30.3 27.0 28.8 31.6 33.4 30.1 31.9 12.5 6.0 0.8 n/a n/a 2.2
16SL,
17S &
18S
200/208-3-60 125 125 125 125 89.7 93.8 86.4 90.4 99.9 103.9 96.6 100.6 40.6 13.8 1.7 13.2 n/a 5.0
230-3-60 125 125 110 125 80.6 84.2 77.5 81.1 89.8 93.4 86.7 90.3 36.8 12.0 1.5 12.0 n/a 4.3
380-3-50 60 60 60 60 42.8 44.4 41.4 43.0 47.5 49.2 46.2 47.8 19.0 7.0 0.9 7.0 n/a 2.6
460-3-60 60 60 60 60 40.3 42.2 38.9 40.7 44.9 46.8 43.5 45.3 18.4 6.0 0.8 6.0 n/a 2.2
19S
200/208-3-60 125 125 125 125 126.2 126.1 126.2 126.2 136.3 136.3 136.3 136.3 40.6 13.8 1.7 33.1 n/a 5.0
230-3-60 125 125 125 125 113.5 113.5 113.5 113.5 122.7 122.7 122.7 122.7 36.8 12.0 1.5 30.0 n/a 4.3
380-3-50 80 80 80 80 59.5 59.5 59.5 59.5 64.3 64.3 64.3 64.3 19.0 7.0 0.9 17.0 n/a 2.6
460-3-60 70 70 70 70 56.8 56.8 56.8 56.8 61.4 61.4 61.4 61.4 18.4 6.0 0.8 15.0 n/a 2.2
NOTES:
1. Electrical system must be securely grounded.
2. Direct-Fired table is based on a Power Flame burner.
3. Field wiring must conform to N.E.C. and all other applicable local codes.
4. Incoming wire to chiller must be copper only. Aluminum wiring is not permitted.
5. Connection lugs in power panel will accept incoming wire range of #14 AWG through #1/0 AWG for 380 volt and 460 volt chillers.
For 200, 208 and 230 volt chillers, lugs will accept #4 to 350 MCM wire.
