Introduction
3
1.3 Components
When unpacking your JFC-130/130HP, you should find the following standard equipment in the carton.
If any items are missing, please notify your JRC dealer immediately.
(1) Standard Equipment
JFC-130
Description Model No. Qty Remarks packing
Display unit NWZ-146 1
Video cable CFQ-6901 1 5 m with connectors
Power cable CFQ-6900 1 5 m with connectors
Tapping screws BRTG07127 4
M6.2´25
Washer BRTG00642 4 M8
Display unit
NWZ-146
Keyboard unit NCH-562 1 with 5m cable
Processing unit NJA-1130 1
Spares 7ZXBS0004 1 Fuse = 2 pieces
Power cable CFQ-8383-3 1 3 m
with 4P connectors
Instruction manual 7ZPBS2506 1
Tapping screws BRTG03052 4
M5´20
Velcro MTZ302573 2
Color echo
sounder
JFC-130
Control unit
NCM-774
Transducer Depends on the frequency
and mounting method
1 or 2
JFC-130ＨＰ
Description Model No. Qty Remarks packing
Display unit NWZ-146 1
Video cable CFQ-6901 1 5 m with connectors
Power cable CFQ-6900 1 5 m with connectors
Tapping screws BRTG07127 4
M6.2´25
Washer BRTG00642 4 M8
Display unit
NWZ-146
Keyboard unit NCH-562 1 with 5m cable
Processing unit NJA-1130HP 1
Spares 7ZXBS0004 1 Fuse = 2 pieces
Power cable CFQ-8383-3 1 3 m
with 4P connectors
Instruction manual 7ZPBS2506 1
Tapping screws BRTG03052 4
M5´20
Velcro MTZ302573 2
Color echo
sounder
JFC-130ＨＰ
Control unit
NCM-774HP
Transducer Depends on the frequency
and mounting method
1 or 2
(2)Optional Accessories
Description Model No. Qty Remarks
Interface mounting parts 7ZZBS0006 1 Two connectors, etc.
Remote control switch NCH-466E 1 With 4m cables
Rectifier NBA-3263 1 Input:100/220VAC,
output:24VDC
Video output unit CAD-239 1 For remote display
