Specifications
62
SECTION 9 Specifications
Display 10.4-inch color LCD
(horizontal or vertical mount)
Resolution 640´480 pixels
Presentation 16-color gradations
(4 display colors and 4 background
colors); all user-selectable.
Shift 0 to 1500 unit,
in 1 steps (m, feet, fathom, special)
Display ranging
Manual Panel key setting/15-range presets
(usually, every 5 to 2000 m),
step mode
Auto ON/OFF
Depth unit Meter, feet, fathom, and special
unit(0.3 to 1.999 m) selectable
Display mode Mode select rotary switch,
graph key, A-scope key
Standard High-/low-/dual-frequency
Standard and VRM
expand
High-/low-/dual-frequency
Standard and bottom
lock expand
High-/low-/dual-frequency
Mixed Three display mode(vertical)
A-scope A-scope displayed on all displays
*1
.
Graph function Graphs displayed on all displays
(sensor options required).
Cursor Variable range marker with
depth indication; one decimal
place displayed for depths less
than 100 m.
Depth scale Line and numeral displayed in
the right-hand side of the
screen, or displayed in the
middle.
Bottom depth Numerically indicated at the
lower left corner of the display
screen.
Alarm function *
2
(Set with the remote control)
Fish school alarm Can be set in a range of 2000
(m, feet, or fathoms) from the
zero line.
Water temperature
alarm *
3
Can be set in a range of 14°F
(-10°C) to 122°F (+50°C).
Picture recording Up to two right half screens
recorded
*2
Color sample Displayed all the left-most end
of the screen (ON/OFF).
Timing mark 30-second (drawing for 15
second, non-drawing for 15
seconds)
Interference
control
Manual/automatic
Draft adjustment Menu-selectable from 0 to 20 in
units of 0.1.
Chart scroll 1/1, 1/2, ..., 1/9, and stop
Marker Vertical line
(with marker output terminal)
Backup EEPROM
Brightness Knob
Panel illumination Fixed
Gain control Knob
STC (Bubble noise
rejection)
Menu-selectable curves,
with intensity set by a panel
semi-fixed variable resistor.
Clutter (Noise
suppression)
Knob
Color rejection Set on menu displays.
Frequencies 200, 75, 50, 38, and 28kHz
Transmitter output JFC-130: 1kW
JFC-130HP: 3kW
FM transmission 200kHz
Output reducer Built-in
Transmitted pulse
width
0.2 to 3.0 ms:
selectable between long and
short (depends on range)
Sounding rate JFC-130:
600 cycles/minute (0-40m)
JFC-130HP:
300 cycles/minute(0-40m)
Depth data output JRC and NMEA0183 output
Custom presetting Three Kinds
Water temperature
input
JRC and NMEA0183 water
temperature sensor
Power supply 12/24/32VDC(10.8 to 42VDC)
External
dimensions
NWZ-146:230(W)´327(H)´155(D)
NCH-562: 290(W)´45(H)´123(D)
NJA-1130: 340(W)´130(H)´280(D)
Mass NWZ-146:2.8kg
NCH-562: 1kg
NJA-1130: 6kg
*
1
: Excluding mixed displays.
*
2
: An optional remote controller is needed.
*
3
: A water temperature sensor is needed to indicate
water temperatures.
