Operation
22
<
Varying the BOTTOM LOCK EXPAND Mode Range (BTM EXP.RANGE)
The BOTTOM LOCK EXPAND mode range is selectable from five preset
choices. These five presets may be varied as desired (in a range of 1 to 50).
To vary the BOTTOM LOCK EXPAND mode range, follow these steps:
l Choosing from among five BOTTOM LOCK EXPAND mode range
1.
Press the
and keys at the same time to call up the main
menu.
2.
Using the
or key, move to “2.BTM EXP. RANGE.”
3.
Using the
or key, move to the range to choose.
4.
Press the
GRAPH
key to return to the fishfinding display.
l Varying a preset BOTTOM LOCK EXPAND mode range
1.
Press the
and keys at the same time to call up the main
menu.
2.
Using the
or key, move to “2.BTM EXP. RANGE” and
press the
MARK
key.
3.
Using the
or key, move to the range to vary.
4.
Using the
or key, increase or decrease the range value.
5.
Repeat steps
3
and
4
to vary other ranges as needed.
6.
Press the
MARK
key to return to the main menu.
7.
Press the
GRAPH
key to return to the fishfinding display.
1.PRESET STD RANGE ≫ １ ２ ３ ４ ５
10 20 30 40 50
６ ７ ８ ９ １０
RANGE 60 80 100 150 200
１１ １２ １３ １４ １５
250 300 400 500 800
STEP
10
▲ 2.BTM EXP.RANGE ≫ 2 3 4 5 10
▼ 3.B.DISCRIM RANGE ≫ 10 20 30 40 50
4.VRM EXP.RANGE ≫ 5 10 15 20 50
5.STD RANGE MODE PRESET STEP AUTO
6.BACK COLOR NORMAL 1 2 3
7.COLOR MODE NORMAL 1 2 3
8.USER COLOR ≫
9.DISPLAY ≫
10.SET GRAPH ≫ DEPTH/ DEPTH/
TEMP BH
11.UNIT ≫
GRAPH
:
RETURN TO F/F
MARK
:
GOTO SUB MENU
Main Menu 2.BTM EXP RANGE
BTM EXP.RANGE
Ａ Ｂ Ｃ Ｄ Ｅ
▲ 5 10 15 20 50
▼
MARK
:
RETURN TO MENU
BTM EXP.RANGE
To Next Page
