Operation
16
Calling up the fishfinding menu ( + key)
Calling up the fishfinding menu, press the and keys at the same
time.
The fishfinding will then appear onscreen, proving a listing of 12 setup
items.
Press the
or key to move from one item to the next.
key: Moves to the item right above.
key: Moves to the item right below.
Item names followed by
》
have a submenu to call up further setup.
To move from one value to the next within an item, press the
or
key.
Calling up a Submenu (
MARK
key)
To call up a submenu from the fishfinding menu, follow these steps:
1.
Using the
or key, move to the item from which to call up a
submenu.
2.
Press the
MARK
key.
Returning to the Fishfinding Menu (
MARK
key)
To return from a submenu to the fishfinding menu, press the
MARK
key.
Press the
GRAPH
key to exit the WHITE LINE submenu to the
fishfinding menu.
Exiting the Fishfinding Menu to a fishfinding display (
GRAPH
key)
To exit the fishfinding menu to a fishfinding display, press the
GRAPH
key.
To exit any menu, press the
CUST OM
key to display CUSTOM menu
and then press the
CUST OM
key twice.
Call up and Exiting the STC ADJUST Menu (
MARK
+
GRAPH
key)
To call up the STC ADJUST menu, press the
MARK
and
GRAPH
keys at the
same time.
To return from the STC ADJUST menu to the fishfinding display, press the
MARK
and
GRAPH
keys at the same time.
1.COLOR REJ. ≫
2.WHITE LINE ≫ LO FRQ OFF HI FRQ OFF
3.ADJUST FREQ. ≫ LO FRQ 50.0 HI FRQ 200.0
4.TX PULSE WIDTH LONG SHORT
5.TX CYCLE MODE SYNC. ASYNC.
▲ 6.ADJUST TX CYCLE 0
▼ 7.ＰＤＣ HI FRQ Ａ Ｂ Ｃ Ｄ
LO FRQ Ａ Ｂ Ｃ Ｄ
8.ADC MODE BLU 1 2 3 4 5 STD 7 8 RED
9.STC MODE 50 100 150 200 (m)
10.EXT INPUT DISP OFF DISP ON
11.SIG.PROCESS OFF 1 2
12.SCROLL STEP 1 2 3
GRAPH
:
RETURN TO F/F
MARK
:
GOTO SUB MENU≫
Fishfinding Menu
COLOR REJECTION
▲
SELECT LEVEL
▼
DISP.ON/OFF
MARK
:
RETURN TO F/F MENU
Submenu Display Example
(COLOR REJECTION)
STC ADJUST
LO FRQ HI FRQ
▲ 40 40
▼
STC ADJUST Menu
To Next Page
