Operation
12
Menu Displays
The four menu displays available are the main menu, the fishfinding menu,
the record/replay menu, and the custom menu.
The main menu and the fishfinding menu are used to make operational and
screen display settings. Submenus are available from some setup items in
these two menus. The record/replay menu is used to record current settings.
The custom menu permits you to reset the current settings to their
prerecorded values.
Main Menu see page 15
Fishfinding Menu see page 16
Record Menu see page 17
Custom Menu see page 17
1.PRESET STD RANGE ≫ １ ２ ３ ４ ５
10 20 30 40 50
６ ７ ８ ９ １０
RANGE 60 80 100 150 200
１１ １２ １３ １４ １５
250 300 400 500 800
STEP
10
▲ 2.BTM EXP.RANGE ≫ 2 3 4 5 10
▼ 3.B.DISCRIM RANGE ≫ 10 20 30 40 50
4.VRM EXP.RANGE ≫ 5 10 15 20 50
5.STD RANGE MODE PRESET STEP AUTO
6.BACK COLOR NORMAL 1 2 3
7.COLOR MODE NORMAL 1 2 3
8.USER COLOR ≫
9.DISPLAY ≫
10.SET GRAPH ≫ DEPTH/ DEPTH/
TEMP BH
11.UNIT ≫
GRAPH
:
RETURN TO F/F
MARK
:
GOTO SUB MENU
Main Menu
1.COLOR REJ ≫
2.WHITE LINE ≫ LO FRQ OFF HI FRQ OFF
3.ADJUST FREQ. ≫ LO FRQ 50.0 HI FRQ 200.0
4.TX PULSE WIDTH LONG SHORT
5.TX CYCLE MODE SYNC. ASYNC.
▲ 6.ADJUST TX CYCLE 0
▼ 7.ＰＤＣ HI FRQ Ａ Ｂ Ｃ Ｄ
LO FRQ Ａ Ｂ Ｃ Ｄ
8.ADC MODE BLU 1 2 3 4 5 STD 7 8 RED
9.STC MODE 50 100 150 200 (m)
10.EXT INPUT DISP OFF DISP ON
11.SIG.PROCESS OFF 1 2
12.SCROLL STEP 1 2 3
GRAPH
:
RETURN TO F/F
MARK
:
GOTO SUB MENU≫
Fishfinding Menu
RECORD MENU
1 2 3
MARK
:
RECORD CUSTOM SETTINGS
CUSTOM
:
RETURN TO F/F
Record Menu
CUSTOM MENU
1 ２ ３
MARK
:
RETURN TO CUSTOM SETTINGS
CUSTOM
:
GO TO RECORD MENU
Custom Menu
