3 Operation and visualization
34
Switch-off event = operating signal
In this case, screen saving is performed by using one logic input (extra code).
The logic input is selected via the “Operating signal” parameter.
Screen saving is deactivated when “Off” is selected.
Diagram
view
Diagram view ➔ Signal type
Here, the representation mode of the measurement and event traces is deter-
mined:
- analog inputs
- analog inputs and event traces
Diagram view ➔ Channel representation
The contents of the channel bar is selected here:
- small measurement
-scaling
-bargraph
- large measurement
-switched off
Diagram view ➔ Channel display
The channels which are displayed in the channel line, in the representation
mode “Scaling” and “Bargraph”, are selected here.
Diagram view ➔ Paper perforations
Can only be selected if the analog channels only and no event traces are dis-
played. When yes is set, paper perforations appear in the diagram, thus giving
the picture the appearance of a conventional chart recorder.
Counter/
integrator
reset
After the password has been successfully entered, the counts for each of the 6
channels can be set to 0 or a defined value in this menu.
When a value has been input (confirm with
E), a message with the new
and the old count is entered in the event list. The time period for the counter/
integrator summation will not be freshly started. The recent counter/integrator
values will also not be stored. If this is required, you have to execute the Up-
date diskette incl. counter function in the Disk manager menu before resetting.
In this way, the recording of the counters/integrators can be restarted, for ex-
ample, after the test run of an installation; the test run values, which are not re-
quired, can thus be eliminated.
You can set a password which is different from that for accessing the configu-
ration. The default value is also 9200. The password can be set in the menu
Configuration ➔ Instrument data ➔ Code No. (Password) ➔ Counter/Int. reset.
