29
3 Operation and visualization
3.2.6 Evaluating the stored measurement data
History The softkey function changes during evaluation and, additionally, the current
zoom factor and the cursor position (date and time) are displayed.
Scroll operation
Using these softkeys, the measurement data display can be scrolled (shifted)
on the screen within the measurement data that are stored in the internal
memory.
H
Measurement acquisition remains active during
history representation.
Cursor (violet)
Current zoom
(magnification)
Scroll forwards fast
(one screen)
Scroll forwards slowly (one pixel line)
History activated
Switch to
softkey functions
Zoom/Search
Date and time of measured
values at the cursor position
Scroll backwards slowly (one pixel line)
Scroll backwards fast (one screen)
Measured value
at cursor position
