4.2 Table of configuration parameters
The table below lists all the instrument parameters. The order in which the pa-
rameters are explained corresponds to the order in which they appear on the
instrument (in the menu structure).
The first column describes the path via the menus and windows to the particu-
lar parameter.
The second column lists the possible settings for the parameter or the possi-
ble selections. The factory default setting in this column is always shown bold.
The third column contains a description of the parameter, or the possible se-
lections, if the parameter and its function or its selection is not self-evident.
4.2.1 Parameter setting
Parameter Value/selection Description
Contrast Parameters
➔ Contrast
0—16 — 31 Contrast of display
Speed indication Parameters
➔ Speed indication
in mm/h,
Time/div,
Storage rate
The selected display mode
is shown in the diagram
representation
Switch-off event Parameters
➔ Display off
➔ Switch-off event
Waiting time,
Operating signal
The type of display switch-
off is selected here
Waiting time Parameters
➔ Display off
➔ Waiting time
0 — 32767min Time after which the dis-
play is switched off. Any
key stroke will re-activate
the display. The parameter
can only be entered when
the parameter Switch-off
event is set on “Waiting
time”. 0 = no switch-off
Operating signal Parameters
➔ Display off
➔ Operating signal
Off,
Logic inp1 — 4
If one of the 4 logic inputs
(extra code) is set to “off”
and operated, then the dis-
play will be switched off.
The parameter can only be
entered when the parame-
ter Switch-off event is set
on “Operating signal”.
Signal type Parameters
➔ Diagram view
➔ Signal type
Analog input
Analog&Event
Determines which mea-
surements are graphically
displayed
Channel
representation
Parameters
➔ Diagram view
➔ Channel
representation
Meas. small,
Scaling,
Bargraph,
Meas. large,
Off
Determines the contents of
the channel line (header)
