61
4 Configuration parameters
4.2.8 Configuration - Operating functions
4.2.9 Configuration - Texts
Operating signal
outputs
Configuration
➔ Outputs
➔ Relay K2 — K3
➔ Operating signal
Off,
Logic inp1 — 4,
Logic channel 1 — 6,
Low alarm 1 — 6,
Low comb. al.,
High alarm 1 — 6,
High comb. al.,
Counter/I al. 1 — 6,
C/I comb. al.,
Comb. alarm,
Memory al.,
Error,
Modbus-Flag
The configured signal is
output to the relay.
Parameter Value/selection Description
External texts
logic input 1 — 4
Configuration
➔ Operating functions
➔ External texts
➔ Logic input
1—4
Standard text,
Text 1 — 18,
No text
v Chapter 3.5 “Event list”
v Chapter 4.2.9
“Configuration - Texts”
External texts
logic channel 1 — 6
Configuration
➔ Operating functions
➔ External texts
➔ Logic channel
1—6
Standard text,
Text 1 — 18,
No text
Can only be used if the
“Math/Logic module”
option is available.
v Chapter 3.5 “Event list”
v Chapter 4.2.9
“Configuration - Texts”
Key inhibit Configuration
➔ Operating functions
➔ Key inhibit
Off,
Logic inp1 — 4,
Logic channel 1 — 6,
Low alarm 1 — 6,
Low comb. al.,
High alarm 1 — 6,
High comb. al.,
Counter/I al. 1 — 6,
C/I comb. al.,
Comb. alarm,
Memory al.,
Error,
Modbus-Flag
As soon as the selected
signal is activated, the
keys are inhibited.
Parameter Value/selection Description
Texte Configuration
➔ Texts
➔ Text1 — 18
20 characters
Text 1 — 18
v Chapter 3.8 “Text input”
