JUMO LOGOSCREEN 500 - Configuration - Counter;Integrator (Option)

55
4 Configuration parameters
4.2.5 Configuration - Counter/Integrator (option)
Trace designation Configuration
➔ Event traces
➔ Event traces 1 — 4
➔ Trace designation
7 characters
BE 1 —4
v Chapter 3.8 “Text input”
Input signal Configuration
➔ Event traces
➔ Event traces 5 — 6
➔ Input signal
Off,
Logic inp1 — 4,
Logic channel 1 — 6,
Low alarm 1 — 6,
Low comb. al.,
High alarm 1 — 6,
High comb. al.,
Counter/I al. 1 — 6,
C/I comb. al.,
Comb. alarm,
Memory al.,
Error,
Modbus-Flag
The event (digital signal)
which is to be recorded is
assigned to an event trace
Trace designation Configuration
➔ Event traces
➔ Event traces 5 — 6
➔ Trace designation
7 characters
xxxx
v Chapter 3.8 “Text input”
Parameter Value/selection Description
Channel Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
1 — 6 Select channel for which
the subsequent parame-
ters are to be configured.
Function Configuration
➔ Counter/Integrator
➔ Counter/Int. channs.
➔ Channel 1 — 6
➔ Function
Off,
Counter,
Integrator,
Oper. time
Select the desired function
here.
v Chapter 2.5 “Counters /
Integrators / Timers”
Type Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Type
Periodic,
External,
Daily,
Weekly,
Monthly,
Yearly,
Total,
Daily from-to
Reporting period.
Select here when the count
is to be stored and reset.
